6. Operation / control EN
12.7.23 V2.1 19 / 24
Information
Note that the EDM input must be bridged if no external contactors are used.
WARNUNG!
.
Danger due to lack of complete validation!
When installing the safety evaluation unit, the “normally-closed” and “nor-
mally-open” contacts could be mixed up. Commissioning the system wit-
hout a legally prescribed complete validation may then result in personal
injury, property damage or environmental damage.
Check that the normally-closed and normally-open connections are cor-
rect.
Before commissioning the system, always carry out a comprehensive
complete validation of the system.
6. Operation / control
6.1 LED displays
Tabelle 9
Operating time The operating time is the maximum time permitted on a sensor between ac-
tuation of both sensor contacts.
Safe condition The safety output is opened / with high resistance.
LED Operatio-
nal readi-
ness
Safety
input 1
Safety
input 2
Safety
input 3
Safety
input 4
Safety output
Position Terminal 2 Terminal
8
Terminal
12
Terminal
15
Terminal
19
Terminal
24
Terminal
25
LED dis-
play
1x green 1x red 1x green
LED off SAE not
ready for
operation
Safety input not actuated Safety out-
put closed
Safety out-
put not clo-
sed
LED flas-
hes
An error has
been detec-
ted
Safety input half actuated
(See “Error messages, troubleshooting” on
page 20)
— —
LED lights
up
SAE ready
for opera-
tion
Safety input actuated Safety out-
put not clo-
sed
Safety out-
put closed
