CHAPTER 2 PRODUCT SPECIFICATION
2.1 GENERAL FEATURES
Maximum accumulated length of sensing cable : 200m
Precision to locate leak location : +/-1m or 0.5%
Failsafe operation : Ability to operate in loop operation
Ability to detect liquid leakage during cable break
Display : Permanent backlight with LCD of 4 lines x 20 English characters
Sound Alarm : 90dB max. buzzer with silencing button
System Menu : Configuration Modbus slave number and sound
Time to display Leak/Trouble from supervised panel : 18 seconds typical
Liquid Leak detection data : Typically, 20mm in length of liquid (e.g. tap water) in full contact
with sensing cable, leak sensitivity is adjustable
Supervised Panels Identification : By different panel number and name with up to 35 characters
Mechanical dimensions : Rugged ABS UL-VO case of 222 x 146 x 55mm
Ingress Protection : Dust-and splash-proof IP 65
