 Trouble Relay:

 Sensing cable break or Power failure will activate this Trouble Relay.

 Number of “Trouble” Relays: 2 units, Single Pole Double Throw (SPDT).

 Leak Relay:

 Liquid leaked detected on the sensing cable will activate this “Leak” Relay.

 Number of “Leak” Relays: 2 units, Single Pole Double Throw (SPDT).

 Power Supply:

 100VAC~240 VAC input power supply. (Optional: 12 VAC/12 VDC or 24VAC/24VDC is

available upon request. Battery Backup option is also available upon request.)

1.2.3 3L-SP/AP CONTROL PANEL – POWER ON

 Check all power supply cable, dry contacts are properly connected (see all detail wires connection

indication under section 1.2).

 Switch ON AC Power to 3L-SP/AP

 Check 3L-SP/AP in TEST mode or self-initialization:

 An audible alarm/buzzer sound.

 “POWER” LED turn on as GREEN when power supply is in normal condition.

 “LEAK” LED turn off when all sensing cable do not detect any liquid leakage.

o “LEAK” LED will turn on RED when leak occur at any Control Panel.

 “TROUBLE” LED turn off when all wires are properly connected

 “TROUBLE” LED will turn on YELLOW when sensing cable break occur.

 Check LCD displays “ELSA ADV. SYSTEMS SUPERVISION <ON>” after self-initialization has

completed and all are under normal condition.

 “Time” is display on the top left of the LCD.

 “Date” is display on the top right of the LCD.

1.3 TESTING PROCEDURE

 Leak Test:

 Pour some drop of liquid (to simulate liquid leakage) on the floor.

 Check red “Leak” LED turns ON continuously.

 Check display “LEAK” and leak location in meter.

 Check Buzzer continuous sound.

 Leak Relay/Dry Contact will be activated.

 Removed all liquid with dry cloth in spiral way and dry the cable.

 Check 3L-SP/AP, it will clear the fault automatically and the “Leak” LED turns OFF, Buzzer stops

sounding and display “LEAK CLEARED” then comes back normal.

 LCD display will show “Date, Time and SUPERVISION (ON)”

Note: 3L-SP/AP shall detect multi leak (1

leak and 2

leak), but 3L-SP/AP panel cannot show accurate

leak location if the previous leakage alarm not be cleared.
