CHAPTER 1 QUICK GUIDE TO INSTALLATION
1.1 INTRODUCTION
3L-SP/AP is an advance panel of Early Warning Leak Locating System. Once leak is detected, it responses
within 18 seconds and provide liquid leakage location accurately. This panel shall be mounted directly on
the wall or within the enclosure box.
General Features:
 LCD with backlight – 4 lines, up to 35 characters
 Sensing Cable Length – up to 200m per panel
 Communication interface with BMS/EMS & High level RS485/Modbus interface protocol
 4 x Relay (2-Trouble relay & 2-Leak relay)
 Alarm by Buzzer (90dB max.) and LED indicator
1.2 3L-SP/AP PANEL WIRING DETAILS
1.2.1 3L-SP/AP PANEL PIN NUMBER DETAILS
Figure 1: 3L-SP/AP PANEL
A
B
F
C
D
E
G
H
I
1
2
3
4
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
J
K
L
