CHAPTER 3 PRODUCT SELECTION GUIDE

3.1 3L-SP/AP PANEL WITH MULTI ZONES

 Below figure shows how to connect two zones with 3L-SP/AP panel by using jumper cable.

3.2 3L-SP/AP PANEL FAIL SAFE LOOP BACK CONNECTION DETAILS

Below figure shows how to do the fail-safe loop back cable connection with 3L-SP/AP panel by using

“Leader cable (Front) and Leader cable (Back)”. This unique Fail-safe loop back feature shall continue to

detect leak if there is a cable break.

Figure 6: Schematic diagram for 3L-SP/AP with multi zones

Figure 7: 3L-SP/AP Fail -Safe loop back connection
