3.6 3L-SP WITH 3L-SP/AP CONNECTION DETAILS
3L-SP Panel
Figure 12: Schematic diagram for 3L-SP with 3L-SP/AP
SP/AP
ZONE 1
SP/AP
ZONE 2
SP/AP
ZONE 4
SP/AP
ZONE 3
SP/AP
ZONE 5
