Function Testing:
 Turn ON Power Supply to 3L-SP/AP (Supervising & Locating Panel) ,the system will go into
an auto self-initialization mode.
Passed Failed
1.
Check Alarm/buzzer sounded momentarily upon power up.
2.
Check “Leak” & “Trouble” LEDs switch-on for about 1 second
on 3L-SP/AP.
3.
Check Sensing cable length of each MODULE’s zone tally to the actual length
laid.
4.
Check Dry Contacts are in the correct status. (NC/NO)
5.
Check System is operating normally (under no fault condition).
LCD display is in normal condition for 3L-SP/AP .
6.
Check Hold down clips are fixed at correct position to properly hold the
sensing cable in place.
Check Tag/Label is stuck and marked precisely with distance on the sensing
cable.
Remarks: _______________________________________________________________________________
