Elsteam MISTRAL - Operation; Draining Water; Washing Reservoir; Operating Mode Configuration

06/2022
| 41 |
924EHUCE4.00 - Mistral Humidier
9. OPERATION
9.1 DRAINING WATER / WASHING RESERVOIR
The water reservoir can be emptied in the following cases:
• When powering up;
• After an idle time determined by parameter C0 (if C0 ≠ 0);
• After an active time determined by parameter C1 (if C1 ≠ 0);
• Inthecaseofthersthightemperaturealertevent(parametersA1 and A2);
• Inthecaseofmaintenance,manualemptyingisinitiatedbypressingandholdingthe
button for at least 4 seconds.
Inthecaseofemptyingthereservoirduetoinactivity,theMistral humidifier will run the fan for a time F5 to dry the reservoir. If
thereisademandforhumidity,thehumidifierwillfillthereservoir.
Attheendofeachemptyingphase,thedrainvalveiskeptopenforanother2seconds.
9.2 OPERATING MODE CONFIGURATION
Whenpoweringup,whiletheLEDsareblinking,pressthe button for at least 1 second to enter the analogue input
configuration menu.
Press the button again until the desired operating mode configuration is selected and press the button to confirm
your choice.
Par. Description MU Range
CFG
Operating mode.
0=Stand-alone,ON/OFFoperation,alertrelay;
1=Stand-alone,proportionaloperation,alertrelay;
2=Stand-alone,operationwith4...20mAsensor,alertrelay;
3=Stand-alone,operationwith0...10Vsensor,alertrelay;
4=Stand-alone,operationwithresistivehumiditysensor,alertrelay;
5=Master,ON/OFFoperation;
6=Master,proportionaloperation;
7=Master,operationwith4...20mAsensor;
8=Master,operationwith0...10Vsensor;
9=Master,operationwithresistivehumiditysensor;
10 = Slave.
--- 0...10
DependingontheLED(s)on,onemodeofoperationischosen.
Inthetableonthenextpage,youcanfindtherelationbetweenLED ON - OPERATING MODE.
