Elsteam MISTRAL - Page 45

06/2022
| 45 |
924EHUCE4.00 - Mistral Humidier
Example 50% Humidity Setpoint:
5
10
20
30
50
Fig. 37. Example of humidity setpoint conguration at 50%
LED
LED ON/OFF ON OFF OFF OFF OFF
Humidity value 50% --- --- --- ---
Example 75% Humidity Setpoint:
5
10
20
30
50
Fig. 38. Example of humidity setpoint conguration at 75%
LED
LED ON/OFF ON OFF ON OFF ON
Humidity value 50% --- 20% --- 5%
