SYSTEM SETUP
Connection to the mains supply
SPEAKER OUTPUT TERMINAL
SR
SW
SL
SR
CEN.
FL
FUSE T 1A
R
220-240V
~50/60Hz
220-240V
~50/60Hz
ITEM NR.:
AV RECEIVER
220-240V~ 50/60Hz
AVR-280
11040.01
200W MAX
OPT. VIDEO
COAX
VIDEO
AUX 1
AUX 2
SUB
SCART IN/OUT
DIGITAL DIGITAL
Do not connect the receiver to the mains supply before all system
connections have been made correctly.
Check that all connections have been made correctly before connecting the
receiver to the mains supply.
Check that the mains voltage is 220-240V~50/60Hz before connecting the
receiver to the mains supply.
Connection to the mains supply
Before inserting the power plug into the socket it should be checked that all other system connections are
correct and safe.
Insert the power plug into a suitable socket.
If the receiver is to be used abroad, you may need an adapter.
