Primary Switch Mode Rectifier
PSS30
User manual
Page 17 (28)
Eltek Valere Industrial ©2008 UM_PSS30_E_R00
7.2 Front view/Operation elements 216V version
Digital display for output voltage and -current/
indication of the parameters and related values in
the adjustment mode
LED indications
Adjustment keys „UP“ and „DOWN“
Input-side fuse; ON-/OFF switch
DC connectors X2
Signals/CAN-Bus connectors X4
Mains connector X1
PE connector (M4 bolt)
