Page #23 background imageLoading...
Page #23 background image
Primary Switch Mode Rectifier
PSS30
User manual
Page 23 (28)
Eltek Valere Industrial ©2008 UM_PSS30_E_R00
10. Technical data
10.1. General technical data
Nominal input voltage 230V
AC -20/ +15%
Inrush current 15A at 10ms
Recommended mains fuse gL 16A
IV line IV line acc. DIN 41 772/ DIN 41773
Emission acc. EN50081-1
Conducted interference voltage acc. EN 55011/EN55022
class "B"
Radiated electromagnetic
field strength acc. EN 55011/EN55022
class "B"
Immunity acc. EN50082-2
Cabinet ESD-test acc. EN61000-4
part 2; 6kV contact;
8kV air discharge
HF-field acc. EN61000-4 part 3;
10V/m (30Mhz - 1GHz)
Power wires Burst-test acc. EN61000-4
part 4; 2kV
Surge-test acc. EN61000-4
part 5;
4kV unsymmetric;
2kV symmetric
Signal wires Burst-Test acc. EN61000-4
part 4; 2kV
Surge-Test acc. EN61000-4
part 5; 2kV unsymmetric
Protection (electr.) with safe decoupling at
V
O 60VDC acc. VDE0100
part 41011.83 cap. 4.3.2;
at 110V
DC VO 220VDC acc. VDE
0160 5.88 cap. 5.6
Dynamic voltage difference 3 % at load changes between 10
% - 90 % - 10 % of nominal output
current (regulation time 1 ms)
Short circuit capability continuous short circuit proof
(constant current control)
