Primary Switch Mode Rectifier
PSS30
User manual
Page 24 (28)
Eltek Valere Industrial ©2008 UM_PSS30_E_R00
Protection / monitoring /
signalling front side 2-pole MCB (16A)
Mains monitoring „Mains“ green LED
Operation monitoring „V
O1 “ green LED
Operation monitoring „V
O2 “ green LED
Output voltage low „V<„ green LED with
relay contact
Output voltage high „V>„ red LED
Constant current mode „I
O“ yellow LED
Over-temperature/general fault red LED
Digital instruments:
Ammeter Indication of 00,1 to 99,9A
DC
Voltmeter Indication of 00,1 to 999V
DC
External functions
signal V< via potential-free contact
(contact charge: 24V
DC/1A,
120V
AC/0,5A)
General fault alarm signal via potential-free relay contact
(10s time delay)
(contact loading: 24V
DC/1A,
120V
AC/0,5A)
Power measuring for active current distribution
discharge test / boost charge voltage values adjustable
Temperature compensated
voltage regulation temperature coefficient
4mV/K per cell with external
temperature sensor (optional),
temperature coefficient adjust-
able
External sensor lead connection
for output voltage Signal via optocoupler „V
O O.K.“
„Mains O.K.“
Constant current operation „I
const
“ signal via optocoupler
External ON/OFF if required
Parallel operation max. 50 units, consumer load
sharing approx.10%
Design 1/3 x 19" unit for mounting in
cabinets according to DIN 41494
Protection class IP 20
Cooling Fan cooling
