Primary Switch Mode Rectifier
PSS30
User manual
Page 25 (28)
Eltek Valere Industrial ©2008 UM_PSS30_E_R00
Ambient temperature 0°C to 45°C for single unit opera-
tion
0°C to 40°C for cabinet assembly
operation
Storage temperature -30°C to + 70°C
Environmental conditions IEC 721 part 3-3 Class 3K3 / 3Z1 /
3B1 / 3C2 / 3S2 / 3M2
Operation altitude up to a maximum of 1500 m
Mechanical strength and
vibration resistance acc. to VDE 0160 issue. 5.88
Pt. 7.2.2
Finish RAL 7035 (front plate)
Dimensions see section 10.3 and 10.4
“Dimensional drawings”
Weight: approx. 12,4kg
Electrical connectors:
Input connection X1 angular plug type GDM 2011; 3-
pole
DC-output / signalling X2 24-108V
DC: SUB-Min-D-connector
21WA4
216V
DC:
Front side terminals 8x4mm
2
,
COMBICON (DC-output);
Front side terminals 15x1,5mm
2
(signal contacts)
Protective conductor connection bolt M4
