26 BA-en-3031-2004_KNH35
4.3 Overview of functions with options and factory settings
Specific setting options for each high voltage output:
Function Description Setting options Factory settings
setpoint
XX.X kV
Setting the output voltage in the
„voltage constant“ operating mode.
3.0…30.0 kV
in 0.1 kV increments
3.0 kV
setpoint
Y.YY mA
Setting the output current in the „current
constant“ operating mode.
0.20...5.00 mA
in 0.01 mA increments
0.00 mA
operating mode Setting the operating mode. voltage constant
current constant
voltage constant
U
max
XX.X kV Setting the maximum output voltage in
the „voltage constant“ operating mode.
3.0…30.0 kV
in 0.1 kV increments
30.0 kV
I
max
Y.YY mA Setting the maximum output current in
the „current constant“ operating mode.
0.20...5.00 mA
in 0.01 mA increments
5.00 mA
U limit XX.X kV Setting the voltage limit in the „current
constant“ operating mode.
3.0…30.0 kV
in 0.1 kV increments
30.0 kV
I limit Y.YY mA Setting the current limit in the „voltage
constant“ operating mode.
0.20...5.00 mA
in 0.01 mA increments
5.00 mA
limitation type If the selected current or voltage limit is
exceeded, the generator is switched off
or the output value is limited.
limit
switch off
limit
ramp time The ramp time determines the time in
which the output voltage reaches its
setpoint.
0…9 seconds 3 seconds
ext. setpoint With this function enabled, the setpoint
will be defaulted as 0...20 mA or
0...10 V signal.
NO
YES
NO
release mode Mode of operation of the high voltage
release function
intern
extern
intern + extern
intern
release source Source of the external high voltage
release
24V-signal
Analog. setpoint
24V-signal
autostart If this function is activated, the genera-
tor will automatically switch on the high
voltage (only if <NO> is selected for
<Ext. HV>).
NO
YES
NO
Function Description Setting options Factory settings
limit. signal A signal can be read out at the analog
interface if the current or voltage limit is
reached.
YES
NO
NO
