Elvox Vimar 40540 User Manual

IT
32
40540 - 40542 - 40540.D - 40547
Function/configuration setting
Dip switch 1-12
range
[aaaa] bbbb
1
Main ID setting * (no default setting)
Note: The entryphone will search for any other
devices already configured with the same ID.
During this phase, the white and red LEDs will
flash.
0000 aaaa bbbb
0000 0001
ID 1
0000 0010 ID 2
0000 0011 ID 3
0000 0100 ID 4
....
0001 1110 ID 30
....
1100 1000 ID 200
2
Secondary ID setting *
Note: The entryphone will search for any other
devices already configured with the same ID.
During this phase, the white and red LEDs will
flash.
0001 01aa bbbb (1st master
unit secondary)
0001 10aa bbbb (2nd master
unit secondary)
0001 11aa bbbb (3rd master
unit secondary)
00 0001
ID 1 …
11 0010
ID 50
3
Deleting programming and restoring default
values
1010 1010 1010 (none)
4
Configure the intercom push button to PI or
specific control unit *
0010 aaaa bbbb
+ button to configure
0000 0001
ID 1
0000 0010 ID 2
0000 0011 ID 3
....
1100 1000
ID200
1100 1001
switchboard 1
...
1100 1100
switchboard 4
5
Configure push button to send the lock release
control to a specific outdoor station *
0100 0001 bbbb
+ button to configure
0001
ID 1 …
1111
ID 15
6
Configure push button to send the F1 command
to a specific outdoor station *
Note: The outdoor station number must be
consistent with the flag F1/F2 otherwise an error
is given: if the flag is enabled then only outdoor
station configurations from 1 to 8 are valid, if the
flag is disabled then only the outdoor stations
from 9 to 15.
0100 0010 bbbb
+ button to configure
0001
ID 1 …
1111
ID 15
7
Configure push button to send the F2 command
to a specific outdoor station *
Note: The outdoor station number must be
consistent with the flag F1/F2 otherwise an error
is given: if the flag is enabled then only outdoor
station configurations from 1 to 8 are valid, if the
flag is disabled then only the outdoor stations
from 9 to 15.
0100 0011 bbbb
+ button to configure
0001
ID 1 …
1111
ID 15
Dip switch configuration table
Off position = 0
On Position = 1
