IT
5
40540 - 40542 - 40540.D - 40547
• Absorption in standby 10 mA; maximum current 50 mA (40540, 40542, 40540.D), 50 mA (40547)
• Power supply: from BUS terminals 1, 2 - rated voltage 28VDC
• Ambient class: Class A1 (indoor use)
• IP30 protection degree
• Operating temperature: (-5 °) – (+40) °C (indoor use)
• Operating environment humidity: 10 / 80% (non-condensing)
Technical data
Dimensional data
95 mm
146.6 mm
19.8 mm
(*) Thickness of the device
with the handset raised.
95 mm
200 mm
28.5 mm
22 mm (*)
