40540 - 40542 - 40540.D - 40547
Code for lock/F1/F2/self-start of OS
ID
Code
1
0001
2
0010
3
0011
4
0100
5
0101
6
0110
7
0111
8
1000
9
1001
10
1010
11
1011
12
1100
13
1101
14
1110
15
1111
Code for relay activation
ID
ID 69*H
relay
Code
1
1
A
0001
2
1
B
0010
3
2
A
0011
4
2
B
0100
5
3
A
0101
6
3
B
0110
7
4
A
0111
8
4
B
1000
9
5
A
1001
10
5
B
1010
11
6
A
1011
12
6
B
1100
13
7
A
1101
14
7
B
1110
15
8
A
1111
16
8
B
0000
35
37
Table of Contents
Table of Contents
2
General Information
3
Warnings and Advice
3
Technical Functions
4
Technical Data
5
Dimensional Data
5
Handset Entryphone 40540 - 40542 - 40540.D
6
Keys and Status Leds (Front View)
6
Internal View (Entryphone Open)
7
Hands-Free Entryphone 40547
8
Keys and Status Leds (Front View)
8
Internal View (Entryphone Open)
9
Installation
10
Wiring Diagrams
14
Operation
16
Answering a Call
17
Lock Release
18
Calling an Indoor Station (Intercom)
19
Calling a Reception Switchboard
20
Professional Firm" Function, for Automatic Lock Release
21
General" Apartment Intercom Call (Only for 40542 and 40547 by Default)
21
Paging": Sending a One-Way Public Paging Announcement to Other Hands-Free Devices in the same Group (Only for 40542 and 40547)
21
Alert" Function with Dedicated Input on Terminals AL-M (Only for 40542 and 40547)
21
Simplified" Programming Via Entryphone Push Buttons
22
Identification Code Programming
23
Secondary Identification Code Programming
24
Programming Push Buttons for Intercom Calls (Excluding the Lock Release Button)
25
Programming the Self-Start Push Button to a Specific Entrance Panel (Excluding the Lock Release Button)
26
Programming the Lock Release Button of a Specific Entrance Panel (Excluding the Lock Release Button)
27
Restoring Default Values of Push Buttons
28
Deleting All Programmed Settings
29
Configurations
22
Dip Switch Configuration Mode
31
Firmware Updating
37
