Embraco Fullmotion CF10C - Label Information; Product Specifications

CHAPTER 2. TECHNICAL SPECIFICATIONS 9
2.1.1 Label information
Next image shows the product label description.
Manufacturer code ↑ ↑ Batch code / Serial number
Production site Production date
2.2 Product specications
General Specications
Input rated voltage range 220 V-240 V
Input operating voltage
range
160 V-264 V
Input frequency range 50 Hz to 60 Hz
Control mode Frequency, Drop-in and Serial
Parameter
VEG
VNE
FMF
Maximum input current 2.62 A 5.00 A 5.00 A
Maximum input power 540 W 1100 W 1100 W
Output frequency range 60 Hz to 150 Hz 33 Hz to 75 Hz 60 Hz to 150 Hz
Maximum output current 3.3 A 6.5 A 6.5 A
Compressor speed range
1800 rpm to
4500 rpm
2000 rpm to
4500 rpm
1800 rpm to
4500 rpm
Storage and Operating conditions
Storage humidity < 85%
Storage ambient
temperature
-20 ºC to 85 ºC
Operating humidity < 85%
Operating ambient
temperature
*
-20 ºC to 60 ºC
Air forced ventilation (min)
†
2 m/s
Ingress Protection Grade
‡
IPX0
