CHAPTER 1. INTRODUCTION 2
1.1 Product description
1.1.1 Stand alone inverter
1
2
3
4
Figure 1.1: Stand alone view
Composed by
Indicator Description
1 Plastic body
2 Plastic cover
3
Compressor cable
output connection
4
Input/ Earth/
Communication
cables connection
CF10C inverter series are designed to
be used only in built in appliances, with
not accessible machine compartment.
1.1.2 Institute approval
Institute approval
CF10C Inverter
Approved according to
EN 60335-1
