CHAPTER 4. OPERATION 36
Receive commands structure
Response to: ID CMD LSB MSB CK
Set speed 5Ah 83h
Status*
CK
Read set speed 5Ah 80h
Speed [RPM]
CK
Read operation status 5Ah 83h
Status*
CK
Read power 5Ah 82h
Power [W]
CK
Read starting trials 5Ah 81h
Number of trials
CK
Read bus voltage 5Ah 84h
Voltage [V]
CK
Read temperature 5Ah 88h
Temperature [ºC x 10]
CK
Read power limitation 5Ah 8Ah
Power limitation [W]
CK
Serial set speed
overwrite
A5h C3h [Note] 00h CK
Communication error 5Ah Code** FFh FFh CK
*See Status Data table.
**See Error Code table
[Note]: Serial set speed overwrite status/command:
00h – Serial set speed does not overwrite the thermostat set point
01h – Serial set speed overwrites the thermostat set point
Remark: if there is no serial communication for more than 4 h then the overwrite
command is resetted.
Status Data
H Bit LSB MSB Description
- - 00h Compressor running
- - FFh
Compressor stopped (waiting for
a valid start speed)
0 01h FFh Start failure
1 02h - Overload protection (Note 1)
1 02h FFh Overload (Note 3)
2 04h FFh
Under speed (1550 rpm or lower)
3 08h FFh Wrong rotor position
4 10h FFh Short circuit
5 20h FFh
Over temperature failure (Note
6)
7 80h -
Set speed data out of
specication (Note 2)
7 80h FFh
Set speed data out of
specication (Note 4)
Note 1 : This response occurs when compressor is running with a high load. If the
Data High byte is 00h, compressor is still running.
Note 2 : Response to the out-of-spec set speed data received while the comp is
running.
Note 3 : This response occurs when compressor is stopped due to high load.
Note 4 : Response to the out-of-spec set speed data received while the comp is
