EMC VNX Series Hardware Information Guide

VNX8000 DAE cabling
EMC VNX8000 Hardware Information Guide 145
The cables shown in Figure 120 on page 146 are:
Note: The cable colors shown in the example are orange for Bus 0 and blue for Bus 1.
◆ Cable 1, orange, 6-Gb/s SAS I/O module port 0 (SP A) to 2
nd
DAE 1
st
DAE (labels SP A
SAS 5 Port 0 to LCC A)
◆ Cable 2, orange, 6-Gb/s SAS I/O module port 0 (SP B) to 1
st
DAE (labels SP B SAS 5
Port 0 to LCC B)
◆ Cable 3, blue, 6-Gb/s SAS I/O module port 1 (SP A) to 2
nd
DAE (labels SP A SAS 5 Port
1 to LCC A)
◆ Cable 4, blue, 6-Gb/s SAS I/O module port 1 (SP B) to 2
nd
DAE (labels SP B SAS 5 Port
1 to LCC B)

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
