EMC VNX Series Hardware Information Guide

146 EMC VNX8000 Hardware Information Guide
VNX8000 DAE cabling
Figure 120 Example of the VNX8000 File/Unified platform with two DAEs (3U, 15 disk and 2U, 25
disk)
Note: In Figure 120 the VNX8000 File/Unified platform shows a two 2U SPSs, a 4U SPE
(with two SPs), a 1U CS (with an optional 1U CS), two 2U DMEs (with four DMs), a 3U 15
DAE and a 2U 25 DAE.
1
0
6 Gb SAS
X4
#
6 Gb SAS
X4
#
B
A
X4
X4
SP A A0 Port 0
SP B B0 Port 1
0123
0123
0123
0123
0
123
0
123
0
123
0
123
B MGMT
MGMT
B
CS
A
1
2
MGMT
IOIO
B MGMT
MGMT
B
CS
A
1
2
MGMT
IOIO
0
0
LCC B
4
1
LCC B
LCC A
SP A SAS 5 Port 0
2
SP B SAS 5 Port 0
SP B SAS 5 Port 1
3
LCC A
SP A SAS 5 Port 1
Data Mover
enclosure 0
Control Station 0
Control Station 1
(optional)
Data Mover
enclosure 1
Storage
processor
enclosure
SPE standby
power supply
DAE standby
power supply
Disk-array
enclosure 0
Disk-array
enclosure 1
VNX-000808

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
