Appendix B: Field lift tool and accessory kit
EMC VNX8000 Hardware Information Guide 169
Table 60 describes the approximate weight of the VNX-series enclosures used in the VNX
storage systems (including all FRUs installed).
The portable lift commonly used by EMC service personnel has two configurations—one
with the lower mast only and one with both the lower and upper masts. The lower mast
configuration is rated for 400 pounds (181 kg) and is for raising or lowering objects 28U
(4.08 ft, 1.25 m) or less above the floor. The dual mast configuration is rated well under
200 pounds (90.7 kg) and is for raising objects more than 28U (4.08 ft, 1.25 m) above the
floor.
• For installations at or below 4.08 ft (1.25 m), you must use the lower mast
configuration.
• For installations above 4.08 ft (1.25 m), use the accessory kit, rated for 225 pounds
(102 kg), and a support table with the lower mast configuration. This accessory kit and
support table are available from the lift provider.
Table 60 VNX-series enclosure weight comparisons (lb vs. kg)
VNX-series enclosure Weight (lb) Weight (kg)
Disk processor enclosure (DPE), 15-drive 97 44
Disk processor enclosure (DPE), 25-drive 75 34
Storage processor Enclosure (SPE) 53 24
Data Mover enclosure (DME) 53 24
Control Station (CS) 18 8
Standby power supply (SPS) 1U 1.2 kW 47 22
Standby power supply (SPS) 2U 2.2 kW 79 36
Disk-array enclosure (DAE) 3U, 15-drive 68 31
Disk-array enclosure (DAE) 2U, 25-drive 45 20
Disk-array enclosure (DAE) 4U, 60-drive 215 98
Disk-array enclosure (DAE) 3U, 120-drive 165 74.8
