EMC VNXe3200 - Rack and Install System Components

CHAPTER 3
Rack and install
EMC recommends installing the disk processor enclosure (DPE) in the lowest available
location in a cabinet and then installing any optional disk-array enclosure (DAEs) above
the DPE.
CAUTION
The enclosures are heavy and should be installed into or removed from a rack by two
people. To avoid personal injury and/or damage to the equipment, do not attempt to lift
and install an enclosure into a rack without a mechanical lift and/or help from another
person.
l
Install the DPE rails............................................................................................... 16
l
Install the disk processor enclosure...................................................................... 20
l
Installing the disk processor enclosure................................................................. 21
l
Install the DAE rails............................................................................................... 22
l
Install the disk array enclosure..............................................................................26
l
Cabling the DPE to a DAE.......................................................................................27
l
Cable the DPE to DAE.............................................................................................28
l
Attach the storage processors to the network........................................................ 31
l
Power up...............................................................................................................32
l
Verify status LEDs..................................................................................................35
l
Attach the bezels.................................................................................................. 37
Rack and install
15
