EMC VNXe3200 - Unpack the Disk Processor Enclosure

Unpack the disk processor enclosure
The disk processor enclosure (DPE) is a 2U component with either twelve 3.5" drive slots
or twenty-five 2.5" drive slots. Verify that you have received all of the DPE components,
including cables, bezel, rail kit, and mounting screws.
Table 1 DPE container contents
Item
Disk processor enclosure
(DPE) - 2U component with
either
12 3.5" drive slots
or
25 2.5" drive slots
Twelve 3.5" drive slots
Installation
Removing these drives will
make the array unusable
SPD
Removing these drives will
make the array unusable
SPD
Removing these drives will
make the array unusable
SPD
Removing these drives will
make the array unusable
SPD
1
Twenty-five 2.5" drive slots
e0
e1
e2
e3
2
3 4
5
AC
DC
HDMI
X4
6Gb SAS
1GbE
2/4Gb
8Gb
10GbE
1
0
e0
e1
e2
e3
2
3 4
5
AC
DC
HDMI
X4
6Gb SAS
1GbE
2/4Gb
8Gb
10GbE
1
0
Will Make the Array Unusable
Caution: Array Software on drives 0-3. Removing or relocating them
Rail kit, including
Adjustable rails (2)
Adjustable rails and DPE
mounting screws (10)
or
Snap-in rails (2)
Snap-in rails and DPE
mounting screws (6)
Adjustable rails
Unpack your system
6 EMC VNXe2 Series VNXe3200 Installation Guide
