EMC VNXe3200 - Page 36

Figure 31 SP LEDs on the rear side of DPE
e0
e1
e2
e3
2
3
4
5
AC
DC
HDMI
X4
6Gb SAS
1GbE
2/4Gb
8Gb
10GbE
1
0
1
2
3
Physical indications that the storage system is up and running without error:
Table 4 LEDs
Light Emitting
Diodes (LEDs)
Location Status Color Notes
SP A/B Power DPE Rear
1
On Green
SP Status/Fault DPE Rear
2
l
Blinking
l
On
l
Blue, blinking
amber once
every three
seconds
l
Blue
System not yet
initialized.
l
No IP address is
assigned.
l
A management
IP address has
been assigned.
Ethernet I/O DPE Rear
3
On Green
DPE enclosure
fault
DPE Front
4
Off N/A
DPE enclosure
power
DPE Front
5
On Blue
System disk
drives in DPE
DPE Front
6
On Blue disks 0-3 of the DPE
Rack and install
36 EMC VNXe2 Series VNXe3200 Installation Guide
