l
Select Auto Discover (recommended) and click Next to assign a Management IP
address to a VNXe system on the local subnet.
a. View VNXe systems on the subnet, select the Product ID/SN of the system you
are currently attempting to install and configure, and click Next. If you don't see
your VNXe system, click Discover to scan the subnet again. (Make sure that the
system is active and connected to the network.)
b. Specify a name, an IP address, subnet mask, and default gateway for the VNXe
system, and click Next.
c. The Configuration Summary screen appears. When all entries are complete,
click Finish. The Configuring the VNXe Device screen appears while the settings
are implemented. The setup can take up to 10 minutes.
d. Click Start Unisphere to log in to Unisphere on the selected system.
l
Or select Manual Configuration and click Next to assign a Management IP address
to a VNXe system on another subnet.
a. Specify a name, an IP address, subnet mask, and default gateway for the VNXe
system and then click Save file to flash drive.
b. Connect the flash drive to the mini-USB port on either storage processor of the
VNXe system to assign the IP address to the system.
Use an adaptor if you are using a full-sized USB flash drive. A mini-USB adaptor
is included in the DPE system box. Insert the mini-USB adaptor into the mini-
USB port on SP A and connect to your flash drive.
c. Open a web browser to the IP address assigned to the VNXe system.
3. Confirm that the SP Status/Fault LEDs are now out, which indicates that the system's
IP address has been set.
4. Continue with the steps in the VNXe Quick Start Guide. The VNXe Quick Start Guide
provides an overview of the steps remaining to configure, register, license, and
update the software on your system.
Connect
44 EMC VNXe2 Series VNXe3200 Installation Guide
