DPSI RV Family Operating Instructions Version 2.0
Page 17 of 48
5. Installation Instructions and Programming
5.1 Installing the DPSI RV
The simplest method of installation is to glue the receiver directly to the
DPSI RV using double-sided adhesive cellular rubber strips (5-10 mm
thick). The receiver can also be attached separately. In the case of
very high current (a large number of servos) and under combat
conditions, the upper side of the DPSI RV should always remain open
to allow for unobstructed dissipation of heat.
Receiver fastening with double-sided adhesive cellular rubber:
Hint:
The lower side of the DPSI RV where the heat sink resides, may not have
anything pasted on it and may not be covered up and should be at an interval of
at least 30mm (1.2”) from the nearest surface (fuselage floor or similar)! Good
ventilation is required (such as with air scoops or conducted cooling air),
especially if there are numerous servos.
