DPSI RV Family Operating Instructions Version 2.0
Page 37 of 48
5.11. Connecting Accessories
Operation of the DPSI RV with gyroscopes
It is also possible to operate the DPSI RV using gyroscopes. In this
case, you must ensure that the servo(s) is / are not attached to the
gyroscope, but directly to the DPSI RV. The gyroscope is connected to
the existing circuit directly between the DPSI RV and the receiver.
Example:
The gyroscope is to be connected to channels 2 and 5 of the receiver
(for the ailerons). For this purpose, the gyroscope is connected as
usual directly to the receiver (channels 2 and 5). The cables, that
otherwise lead from the DPSI RV to the receiver, are now attached to
the servo outputs
(plugs) of the gyroscope. The servos are contacted
to the DPSI RV following the usual procedure.
Operation of the DPSI RV with MagicBox
It is also possible to operate the DPSI RV using the Graupner/JR
MagicBox. In this case, you have two options: The simplest way is to
attach the servo connection (Rx) of the MagicBox directly to the
receiver. The servos are then attached directly to the MagicBox
(servos 1, 2, 3, and 4) according to the instructions. The supply voltage
for the servos (plug Batt. of the MagicBox) can be drawn from the
DPSI RV using a suitable cable. The transection of the signal wire of
the cable is important, so that only the positive and negative wires are
conducted to the MagicBox.
The second installation option is to supply the servos completely by
means of the DPSI RV. For this purpose, the MagicBox is likewise
attached directly to the receiver (Rx). Only the pulses (orange lines)
are drawn from the MagicBox outputs (servos 1, 2, 3, and 4). The
supply voltage for each servo is drawn from the DPSI RV. Special
“splitting cables” must be prepared for this, however, which draw
pulses and supply voltage from different sources (here: MagicBox and
the DPSI RV).
