9. Technical Data of the DPSI RV-Systems
Power Sources
5, 6, 7-cell NiCad / NiMH cells, Lithium-Ion batteries,
Lithium-Polymer batteries
Operating Voltage Range
5.0V.... 10V
Nominal Input Voltage
6.0V.... 8.4V
Output Voltage
5.0V / 5.3V / 5.6V / 5.9V jumper selectable
5.9V for DPSI 2001 RV
Quiescent current (when off)
Approx. 1µA pro battery
Quiescent current (when on)
Approx. 90mA total
Max. continuous current @ 5.6V
(15 minutes with LiPo batteries)
4A DPSI RV Mini / 8A DPSI 2001 RV / 8A DPSI RV
Max. peak current @5.6V
(10 seconds for with LiPo batteries)
15A DPSI RV Mini / 60A DPSI RV / 60A DPSI 2001 RV
Drop-out losses @ 4A
0.3V DPSI RV Mini / 0.3V DPSI 2001 RV
0.45V DPSI RV
Maximum Power Dissipation
(Continuously)
8W DPSI RV Mini / 15W DPSI RV / 15W DPSI 2001 RV
Number of servos in system
Up to 10 Servos for DPSI RV Mini
Up to 26 Servos for DPSI 2001 RV
Up to 32 Servos for DPSI RV
CE Test
Under terms of 89/336/EWG
Environmental conditions
-10°C.... +50°C (14°F … 122°F)
Permissible temperature range
-25°C.... +85°C (13°F … 185°F)
LCL filtering (EMI)
For each individual servo output
Interference signal suppression at
35 MHz
-20dB @ 35MHz, -34dB @ 100MHz
Dimensions including latches
DPSI RV Mini 5/6
DPSI 2001 RV
DPSI RV
77mm x 99mm x 15,8mm (3.03“ x 3.90“ x 0.62“)
120mm x 75mm x 14,8mm (4.72“ x 2.95“ x 0.58“)
173mm x 85mm x 15,8mm (6.81“ x 3.35“ x 0.62“)
Screw diameter for fastening
4 x 4,2mm (4 x 0.17 in)
Hole spacing for fastening
78,7mm x 67,7mm (3.10“ x 2.66“) DPSI RV Mini
109,0mm x 64,0mm (4.29“ x 2.52“) DPSI 2001 RV
152,3mm x 75,7mm (6,00“ x 2.98“) DPSI RV
Weight
105g (3.70 oz) DPSI RV Mini 5/6
155g (5.47 oz) DPSI 2001 RV
215g (7.58 oz) DPSI RV
15g (0.53 oz) Switch transmitter
Warranty
24 month
