DPSI RV Family Operating Instructions Version 2.0
Page 25 of 48
Two receivers on the DPSI RV:
For all DPSI RV systems, servos can be connected to the receiver
directly. This only makes sense for the “smaller” DPSI RV’s because
these posses only 5, 6 or 10 inputs. Because all components of the
receiver set (receiver and servos) are supplied with the same regulated
voltage, the servo power and servo velocity stays the same (if of same
type).
5.5. Selecting the Batteries
Only commercially available, high current capable batteries are
considerable (NiCad/NiMH), as well as Lithium-Ion (LiIon) and Lithium-
Polymer (LiPo) batteries. These batteries are unlimited applicable
independent of the selected output voltage.
6- or 7-cell NiCad batteries only make sense when using the DPSI
2001 RV or the DPSI RV Mini ESP series, if consumer loads with
higher voltages than e.g. 5.9 volts have to be connected to the MPX
auxiliary outputs. Usually 5-cell NiCad/NiMH or 2-cell LiPo batteries
are used.
