DPSI RV Family Operating Instructions Version 2.0
Page 32 of 48
5.9. Programming of the Batteries
Since the DPSI RV executes intelligent battery voltage monitoring, the
battery type being used must be made known to it (whether 5, 6 or 7-
cell batteries or LiPo batteries are being used, for example). The type
of battery only needs to be programmed once – the programmed
status then remains saved in the microcontroller of the DPSI RV until
eventually replaced by reprogramming.
Programming starts up when only one
battery (regardless of which
type and to which battery connection) is connected to the DPSI RV and
when the latter is turned on.
After it is turned on, the internal buzzer (signal transmitter) of the DPSI
RV switches on for three seconds, to then insert a pause of three
seconds. This displays the operating mode “programming”.
Following this is a one-time beep, which indicates “Battery type No. 1”.
If, at this point, the missing battery is connected to the DPSI RV within
three seconds, this „Battery Type No. 1“ is selected and will be
programmed.
If the missing battery is not attached within the three seconds, a two-
time beep for “Battery type No. 2” is emitted. Here again the user has
three seconds to attach the missing battery, if he wishes to select
(program) this type.
This principle is repeated until the buzzer has beeped five times
(deactivate all tests). If the missing battery is not attached within three
seconds, no programming is done and the system changes to the
normal operating mode.
