6. Hydraulic Installation
Assemblingfootfilterwithlevelprobe.
Levelprobemustbeassembledwithfootfilterusingtheprovidedkit.
  Footvalveismadetobeinstalledintotank’sbottomwithoutsedimentspriming
  problem.
  Completelyunscrewlevelprobe’snutandassemblyasdescribedinfig.(B) 
  payingattentiontotheblackring:itmustbeinsertedfromfloaterside.
  Locknutontheoppositesideofthefloaterusinghandsonly.
ConnectBNCfromlevelprobeintopump’slevelinput(frontsideofthepump).
  Putlevelprobeassembledwithfootfilterintotank’sbottom.
  Warning:Ifthereisamixerinstalledintotank,installasuctionlance  
 insteadoflevelprobe/footfilter.
DeliveryHose.
Completelyunscrewtighteningnutfrompump’sheadandremoveassembling
  components:tightening nut, holding ring and pipe holder.
Assemblyasshowninfig.(A).Inserthoseintopipeholderuntilitreachesthe 
  bottom.
  Lockhoseonpump’sheadbyscrewingdownthetighteningnut.
  Useonlyhandstodoit!
  Connectothersideofthehosetotheinjectionvalveusingthesame  
  procedure.
fig.(B)
toBNCconnector
(pump’slevelinput)
levelprobe
footfilter
tosuctionhose
blackring
fixingnut
