6. Hydraulic installation
Dischargehose.
Insertonesideofdischargehoseintodischargeconnectorasshowninfig(C).
  Insertothersideofdischargehoseintoproduct’stank.
  Duringprimingprocedureproductexceedingwillflowintotank.
  Forprimingprocedureseetherelatedchapter.
InjectionValve.
  Injectionvalvemustbeinstalledonplantfromwater’sinput.
  Injectionvalvewillopenatpressuregreaterthan0,3bar.
fig(C)
Dischargehose
DischargeKnob
ToDeliveryhose
ToSuctionhose
Dischargehose
DischargeKnob
fig.(C)
Todeliveryhose
Tosuctionhose
