I/O sequencer 6.04 6.30 6.31 6.32 6.33 6.34 6.39 6.40 6.42 6.43
Jog reference 1.05 1.13 2.19 2.29
Keypad reference 1.17 1.14 1.43 1.51 6.12
Limit switches 6.35 6.36
Logic function 1 9.01 9.04 9.05 9.06 9.07 9.08 9.09 9.10
Logic function 2 9.02 9.14 9.15 9.16 9.07 9.18 9.19 9.20
Low DC bus operation 6.10
Mains loss 6.03 10.15 5.05
Maximum speed 1.06
Menu 0 set up 11.01 to 11.10 11.27 6.04
Minimum speed 1.07 10.04
Motor map 5.06 5.07 5.08 5.09 5.10 5.11
Motor map 2 Menu 21 11.45
Motorized
potentiometer
9.03 9.21 9.22 9.23 9.24 9.25 9.26 9.27 9.28
Offset speed reference 1.04 1.38 1.09
Onboard PLC 11.47 11.48 11.50
Open loop vector mode 5.14 5.17 5.23
Operating mode 5.14
Output 5.01 5.02 5.03 5.04
Over modulation enable 5.20
PID controller Menu 14
Power up parameter 11.22 11.21
Precision reference 1.18 1.19 1.20 1.44
Preset speeds 1.15 1.21 to 1.28 1.14 1.42 1.45 1.46 1.47 1.48 1.50
Programmable logic Menu 9
PWM output 3.17 8.21
Ramp (accel / decel)
mode
2.04 2.08 6.01 2.03 10.30 10.31 10.39
Regenerating 10.10 10.11 10.30 10.31 6.01 2.04 10.12 10.39 10.40
Relay output 8.07 8.17 8.27 12.41
Reset 10.33 8.02 8.12 8.22 6.14
S ramp 2.06 2.07
Security code 11.30 11.44 5.50
Serial comms 11.23 to 11.26 6.42 6.43
Skip speeds 1.29 1.30 1.31 1.32 1.33 1.34 1.35
Slip compensation 5.08 5.27
Software version 11.29 11.34 11.35
Speed reference
selection
1.14 1.15 1.49 1.50 1.01 1.02
Status word 10.40
Supply 5.05
Switching frequency 5.18 5.35 5.37
Thermal protection -
drive
5.18 5.35 7.04 7.05 7.34 7.35 7.36 10.18
Thermal protection -
motor
4.15 5.07 4.19 4.16 4.25
Thermistor input 8.35
Threshold detector 1 12.01 12.03 12.04 12.05 12.06 12.07
Threshold detector 2 12.02 12.23 12.24 12.25 12.26 12.27
Time - run log 6.22 6.23
Torque mode 4.08 4.11
Trip detection 10.37
10.20 to
10.29
Trip log 10.20 to 10.29
User trip 10.38
Under voltage 5.05 10.15
Table 8-1 Feature look up table
Feature Parameter number (Pr)
