170 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 9
This parameter monitors the reference input of the PID controller.
This parameter monitors the feedback input of the PID controller.
This parameter monitors the error of the PID controller.
14.20 PID reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range ±100.0%
Update rate 21 ms
14.21 PID feedback
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range ±100.0%
Update rate 21 ms
14.22 PID error
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range ±100.0%
Update rate 21 ms
