Introduction
Parameter
x.00
Parameter
description format
Keypad and
display
Serial
communications
CT Modbus
RTU
PLC Ladder
programming
CTSoft Menu 0
Advanced parameter
descriptions
Menu 1
Commander SK Advanced User Guide 43
Issue Number: 9 www.controltechniques.com
Defines preset speeds 1 to 8
The preset speeds are clamped by the maximum set speed (Pr 1.06).
The preset speeds do not go back to the maximum clamp value, if the clamp (Pr 1.06) has been reduced previously.
See Pr 1.30, Pr 1.32 and Pr 1.34 description.
Three skip references are available to prevent continuous operation at a speed that would cause mechanical resonance. When a skip reference
parameter is set to 0 that filter is disabled. The skip reference band parameters define the frequency or speed range either side of the programmed
skip reference, over which references are rejected. The actual reject band is therefore twice that programmed in these parameters, the skip reference
parameters defining the centre of the band. When the selected reference is within a band the lower limit of the band is passed through to the ramps
such that reference is always less than demanded.
This parameter indicates that the selected reference is within one of the skip frequency regions such that the motor speed is not as demanded.
1.21 Preset speed 1 {18}
1.22 Preset speed 2 {19}
1.23 Preset speed 3 {20}
1.24 Preset speed 4 {21}
1.25 Preset speed 5
1.26 Preset speed 6
1.27 Preset speed 7
1.28 Preset speed 8
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 11
Range ±550 Hz
Default 0.0
Update rate 5ms
1.29 Skip reference 1
1.31 Skip reference 2
1.33 Skip reference 3
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 to 550 Hz
Default 0.0
Update rate Background
1.30 Skip reference band 1
1.32 Skip reference band 2
1.34 Skip reference band 3
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0.0 to 25.0Hz
Default 0.5
Update rate Background
1.35 Reference in rejection zone
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Update rate 5ms
NOTE
