Equation 3-1: Chord “L” Dimension
L
cℎord
= L
MeterHousing
+ L
Mount1
+ L
Mount2
−L
Xdcr1
− L
Stalk1
− L
Hldr1
−L
Xdcr2
− L
Stalk2
− L
Hldr2
L
chord
= chord “L” dimension (in) (LA ... LD)
L
MeterHousing
= meter housing length (in)
L
Mount1
= transducer 1 mount length (in)
L
Mount2
= transducer 2 mount length (in)
L
Xdcr1
= transducer 1 length (in)
L
Xdcr2
= transducer 2 length (in)
L
Stalk1
= transducer 1 stalk length (in)
L
Stalk2
= transducer 2 stalk length (in)
L
Hldr1
= transducer 1 holder length (in)
L
Hldr2
= transducer 2 holder length (in)
Tip
The transducer “L” dimension is re-calculated when you run the Transducer Swap-out
utility.
3.3 T-Slot transducer holder removal and
installation
WARNING
CONTENTS MAY BE UNDER PRESSURE
When the meter is under pressure, DO NOT attempt to remove or adjust the transducer
holder of the T-Slot transducer assembly, or loosen the screws holding the T-200
transducer assembly.
Attempting to do so could release pressurize gases, resulting in serious injury or
equipment damage.
Meter repairs Maintenance and Troubleshooting manual
August 2021 P/N 3-9000-791
52 Models 3415, 3416 and 3417 GUSM
