Emerson AVENTICS System Description

1 About This Documentation
1.1 Documentation Validity
This documentation is valid for the AESseries bus couplers for EtherNet/IP, with
material numbers R412018222 and R412088222. The documentation is geared
toward programmers, electrical engineers, service personnel, and system own-
ers.
This documentation contains important information on the safe and proper com-
missioning and operation of the product and how to remedy simple malfunctions
yourself. In addition to a description of the bus coupler, it also contains informa-
tion on the PLC configuration of the bus coupler, valve drivers, and I/Omodules.
1.2 Required and Supplementary Documentation
u Only commission the product once you have obtained the following docu-
mentation and understood and complied with its contents.
Table1: Required and supplementary documentation
Documentation Document type Comment
System documentation Operating instruc-
tions
To be created by system owner
Documentation of the PLC configu-
ration program
Software manual Included with software
Assembly instructions for all current
components and the entire AV valve
system
Assembly instruc-
tions
Printed documentation
System descriptions for connecting
the I/O modules and bus couplers
electrically
System descrip-
tion
PDF file on CD
Operating instructions for AV-EP
pressure regulators
Operating instruc-
tions
Printed documentation
All assembly instructions and system descriptions for the AES and AV
series, as well as the PLC configuration files, can be found on the CD
R412018133.
1.3 Presentation of information
1.3.1 Warnings
In this documentation, there are warning notes before the steps whenever there
is a risk of personal injury or damage to equipment. The measures described to
avoid these hazards must be followed.
Structure of warnings
SIGNAL WORD
Hazard type and source
Consequences
u Precautions
Meaning of the signal words
DANGER
Immediate danger to the life and health of persons.
Failure to observe these notices will result in serious health consequences, in-
cluding death.
WARNING
Possible danger to the life and health of persons.
Failure to observe these notices can result in serious health consequences, in-
cluding death.
CAUTION
Possible dangerous situation.
Failure to observe these notices may result in minor injuries or damage to
property.
NOTICE
Possibility of damage to property or malfunction.
Failure to observe these notices may result in damage to property or malfunc-
tions, but not in personal injury.
1.3.2 Symbols
Recommendation for the optimum use of our products.
Observe this information to ensure the smoothest possible operation.
1.4 Designations
The following designations are used in this documentation:
Table2: Designations
Designation Meaning
Backplane Internal electrical connection from the bus coupler to the valve driv-
ers and the I/O modules
Left side I/O zone, located to the left of the bus coupler when facing its elec-
trical connectors
Module Valve driver or I/O module
Right side Valve zone, located to the right of the bus coupler when facing its
electrical connectors
Stand-alone system Bus coupler and I/O modules without valve zone
Valve driver Electrical valve actuation component that converts the signal from
the backplane into current for the solenoid coil
1.5 Abbreviations
This documentation uses the following abbreviations:
Table3: Abbreviations
Abbreviation Meaning
AES Advanced Electronic System
AV Advanced Valve
BOOTP Bootstrap Protocol
Used to set the IP address and additional parameters for diskless
computers that load their operating system from a boot server.
DHCP Dynamic Host Configuration Protocol
Used to automatically integrate a computer in an existing network;
extension of the Bootstrap Protocol
DNS Domain Name System
I/O module Input/Output module
EtherNet/IP EtherNet Industrial Protocol
FE Ground (Functional Earth)
EDS Electronic Data Sheet
MAC address Media Access Control address
nc not connected
PLC Programmable Logic Controller or PC assuming control functions
UA Actuator voltage (power supply for valves and outputs)
UA-ON Voltage at which the AV valves can always be switched on
UA-OFF Voltage at which the AV valves are always switched off
UL Logic voltage (power supply for electronic components and sensors)
2 Notes on Safety
2.1 About This Chapter
The product has been manufactured according to the accepted rules of current
technology. Even so, there is danger of injury and damage to equipment if the
following chapter and safety instructions of this documentation are not followed.
1. Read these instructions completely before working with the product.
2. Keep this documentation in a location where it is accessible to all users at all
times.
3. Always include the documentation when you pass the product on to third par-
ties.
