Table 2-6. Solar Panel Electrical Characteristics
Characteristic
Value/Range
30W ± 10%
Voltage (@peak power)
17.9V
Current (@peak power)
1.68A
Open Circuit Voltage
22.1V
Short Circuit Current
1.74A
Table 2-7. Solar Regulator Electrical Characteristics
Characteristic
Value/Range
Rated Solar Input
6A
Nominal System Voltage
12V
Maximum Solar Voltage
30V
3 stage charging
Bulk, PWM, and float
Regulation Voltage
14.1V
Float Voltage
13.7V
Temperature Compensation
30 mV / °C
Operating Temperature
40 °C to 70 °C
Humidity
100%
Short Circuit Current
▪
reverse polarity
▪
lightning and transient surges
▪
short circuit
▪
high temperature
▪
overcurrent
▪
reverse current at night
1. The solar controller comes with plastic mounting feet used only for surface mounting
applications. Remove the mounting feet but save the lock nut.
2. The solar controller also comes with fork connectors.
