Table 1-4: Part description for a high temperature enclosure
Item
number
Description Part number Quantity
required
1
(1)
End cap solid 1-360-00-25 1
2
(2)
Electronics enclosure 899-10-110-60 1
3 Plug pipe hex socket 154717-019 2
4 Grounding clamp B18934-004 2
5 Mounting bracket 899-10-230-50 1
6
(3)
Socket head screw 899-10-230-52 4
7 Warning tag-Hazard 899-00-225-04 1
8 Socket head screw 899-10-230-61 2
11 Socket head screw 899-10-230-65 2
13 O-ring FKM 2-4-9163-245 1
14 O-ring FKM 1500093-022 1
15 Washer plastic 1-562-01-827 1
16 Clamp cover 1-504-90-165 1
17 Socket head screw 1-555-27-001 1
18 Terminal block 1505065 2
(1) Enclosure housing and end cap material: stainless steel.
(2)
(1)
(3) Screw length varies on LTM sizes. The screws are not included in the part number package.
NOTICE
The joint between the LME cover and housing is a threaded joint. The joint between the
LME housing and Sensor housing is a spigot joint with a minimum axial length of 26.16
mm (1.030 in), radial length of 3.18 mm (0.125 in), and a clearance of 0.07 mm (0.0028
in).
User manual Introduction
P/N 3-9008-515 March 2019
User manual 23
