Table 1-7: Part description for an NPS 3 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-114 1-504-05-114 2
54 Shaft 1-504-05-622 1-504-05-622 1
Shaft for FCP 1-504-05-623 1-504-05-623 1
55 Bladed rotor 1-307-11-235 1-307-11-236 1
60 Nut 1-561-76-192 1-561-76-192 2
62 Upstream cone-rimmed 1-307-10-435 1-307-10-439 1
Upstream cone-bladed 1-307-10-437 1-307-10-438 1
65 Downstream cone 1-307-10-535 1-307-10-536 1
68 Housing insert 1-307-03-000 1-307-03-020 1
69 Hanger blades 1-307-10-735 1-307-10-736 6
71 Hanger hub 1-307-10-635 1-307-10-636 2
72 Rimmed rotor 1-307-11-237 1-307-11-238 1
75 Flow conditioning plate (FCP)
(optional)
1-307-01-171 1-307-01-171 1
Table 1-8: Part description for an NPS 4 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-115 1-504-05-115 2
54 Shaft 1-504-05-627 1-504-05-627 1
Shaft for FCP 1-504-05-628 1-504-05-628 1
55 Bladed rotor 1-307-11-300 1-307-11-301 1
60 Nut 1-561-76-155 1-561-76-155 2
62 Upstream cone-rimmed 1-307-10-440 1-307-10-444 1
Upstream cone-bladed 1-307-10-442 1-307-10-443 1
65 Downstream cone 1-307-10-540 1-307-10-541 1
User manual Introduction
P/N 3-9008-515 March 2019
User manual 29

Emerson Daniel Series Specifications

General

Type	Flow Meter
Repeatability	±0.1% of reading
Communication Protocol	HART, Modbus, Foundation Fieldbus
Output	4-20 mA, pulse, frequency
Process Connection	Flanged, wafer, threaded
Material	Stainless steel, carbon steel, Hastelloy
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Protection Rating	IP67, NEMA 4X
Fluid Compatibility	Liquids, gases
