Table 1-10: Part description for an NPS 8 unidirectional LTM (continued)
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-118 1-504-05-118 2
54 Shaft 1-504-05-637 1-504-05-637 1
60 Nut 1-561-76-171 1-561-76-171 2
62 Upstream cone-rimmed 1-307-10-450 1-307-10-451 1
65 Downstream cone 1-307-10-550 1-307-10-551 1
68 Housing insert 1-307-03-004 1-307-03-024 1
69 Hanger blades 1-307-10-750 1-307-10-751 6
71 Hanger hub 1-307-10-650 1-307-10-651 2
72 Rimmed rotor 1-307-11-404 1-307-11-405 1
User manual Introduction
P/N 3-9008-515 March 2019
User manual 31

Emerson Daniel Series Specifications

General

Type	Flow Meter
Repeatability	±0.1% of reading
Communication Protocol	HART, Modbus, Foundation Fieldbus
Output	4-20 mA, pulse, frequency
Process Connection	Flanged, wafer, threaded
Material	Stainless steel, carbon steel, Hastelloy
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Protection Rating	IP67, NEMA 4X
Fluid Compatibility	Liquids, gases
