Table 1-13: Part description for an NPS 16 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-122 1-504-05-122 2
54 Shaft 1-504-05-652 1-504-05-652 1
60 Nut 1-561-76-083 1-561-76-083 2
62 Upstream cone 1-307-10-465 1-307-10-466 1
65 Downstream cone 1-307-10-565 1-307-10-566 1
68 Housing insert 1-307-03-008 1-307-03-018 1
69 Hanger blades 1-307-10-765 1-307-10-766 6
70 Cotter pin 1-562-05-639 1-562-05-639 2
71 Hanger hub 1-307-10-665 1-307-10-666 2
72 Rotor assembly 1-307-11-676 1-307-11-677 1
Table 1-14: Part description for an NPS 18 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-123 1-504-05-123 2
54 Shaft 1-504-05-657 1-504-05-657 1
60 Nut 1-561-76-088 1-561-76-088 2
62 Upstream cone 1-307-10-491 1-307-10-494 1
65 Downstream cone 1-307-10-591 1-307-10-594 1
68 Housing insert 1-307-03-009 1-307-03-029 1
69 Hanger blades 1-307-10-770 1-307-10-771 6
70 Cotter pin 1-562-05-656 1-562-05-656 2
71 Hanger hub 1-307-10-696 1-307-10-697 2
72 Rotor assembly 1-307-11-686 1-307-11-687 1
Introduction User manual
March 2019 P/N 3-9008-515
34 Daniel Series 1500 Liquid Turbine Meter, NPS 3-24
