Emerson Daniel Series User Manual

Table 1-11: Part description for an NPS 10 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-119 1-504-05-119 2
54 Shaft 1-504-05-642 1-504-05-642 1
60 Nut 1-561-76-183 1-561-76-183 2
62 Upstream cone 1-307-10-455 1-307-10-456 1
65 Downstream cone 1-307-10-555 1-307-10-556 1
68 Housing insert 1-307-03-005 1-307-03-025 1
69 Hanger blades 1-307-10-755 1-307-10-756 6
71 Hanger hub 1-307-10-655 1-307-10-656 2
72 Rotor assembly 1-307-11-406 1-307-11-407 1
Table 1-12: Part description for an NPS 12 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-120 1-504-05-120 2
54 Shaft 1-504-05-647 1-504-05-647 1
60 Nut 1-561-76-200 1-561-76-200 2
62 Upstream cone 1-307-10-460 1-307-10-461 1
65 Downstream cone 1-307-10-560 1-307-10-561 1
68 Housing insert 1-307-03-006 1-307-03-007 1
69 Hanger blades 1-307-10-760 1-307-10-761 6
71 Hanger hub 1-307-10-660 1-307-10-661 2
72 Rotor assembly 1-307-11-656 1-307-11-655 1
User manual Introduction
P/N 3-9008-515 March 2019
User manual 33

Emerson Daniel Series Specifications

General

Type	Flow Meter
Repeatability	±0.1% of reading
Communication Protocol	HART, Modbus, Foundation Fieldbus
Output	4-20 mA, pulse, frequency
Process Connection	Flanged, wafer, threaded
Material	Stainless steel, carbon steel, Hastelloy
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Protection Rating	IP67, NEMA 4X
Fluid Compatibility	Liquids, gases
