1592026260 IEV22-24D GB r.1.0 21.02.2019 IEV 38/60
Ec 8
Gas selection
0= R22
1= R134a
2= R404a
3= R407c
4= R410a
5= R507c
6= CO2
7= 1234ZE
8= R407F
9= R290
10= R449A
11= R452A
12= R513A
13= R32
14= R450A
15= R454B
16= R454C
17= R452B
18= R1234YF
0
18
Valve 1 configuration
Ec 9
Selection of the bipolar valve body connected
to the driver (WARNING: the unique and
valid reference has to be considered the
datasheet made by valve manufacturer)
0 = Custom
1 = Danfoss ETS – 25/50
2 = Danfoss ETS – 100
3 = Danfoss ETS – 250/400
4 = Alco EX4 – EX5 – EX6
5 = Alco EX7
6 = Alco EX8
7 = Configuration 1
8 = Configuration 2
0
8
Ec 10
Not used
Ec 11
Number of additional steps to achieve
complete closure. When a closing request is
received, the valve starts from the current
number of steps and moves to 0, then closes
for the set number of steps.
For unipolar valves refer to the notes included
in paragraph 7.3.
0
8000
Full steps
