Ec 12
Number of return steps in opening mode after
the valve has been closed completely. These
decompress any closing spring inside the valve
or to prevent sealing the circuit.
For unipolar valves refer to the notes included
in paragraph 7.3.
0
500
Full steps
Ec 13
Maximum number of adjusting steps of the
valve 1
(this value is set automatically by the controller
if EC9> 0).
For unipolar valves refer to the notes included
in paragraph 7.3.
Ec14
8000
Full steps
Ec 14
Minimum number of adjusting steps of the
valve 1
(this value is set automatically by the controller
if EC9> 0).
For unipolar valves refer to the notes included
in paragraph 7.3.
0
Ec13
Full steps
Ec 15
Maximum current value per phase of the
stepper motor
(this value is set automatically by the controller
if EC9> 0)
Ec16
100
mA
x10 mA
Ec 16
Current stand-by value
(this value is set automatically by the controller
if EC9> 0)
0
Ec15
mA
x10 mA
Ec 17
Maximum number of steps per second of the
valve.
For unipolar valves refer to the notes included
in paragraph 7.3.
0
600
Full steps
Valve 2 configuration
Ec 18
Selection of the bipolar valve body connected
to the driver (WARNING the unique and valid
reference has to be considered the
datasheet made by valve manufacturer)
0 = Custom
1 = Danfoss ETS – 25/50
2 = Danfoss ETS – 100
3 = Danfoss ETS – 250/400
4 = Alco EX4 – EX5 – EX6
5 = Alco EX7
6 = Alco EX8
7 = Configuration 1
8 = Configuration 2
0
8
Ec 19
Not used
