Appendix 1 Parameters 91
EV2000 Series Universal Variable Speed Drive User Manual
Table A-1 Parameters
Group F0: Basic Operating Parameters
Para.
Name LCD Display Setting range Unit Factory setting Modif.
F0.00
Reference frequency
selector
FREQ SET
MODE
0:Digital input 1:set the reference via ▲ and ▼ keys
on panel
1:Digital input 2:set the reference via terminal UP/DN
2:Digital input 3:set the reference via serial port
3:Set the reference via VCI
4:Set the reference via CCI
5:Set the reference via PULSE terminal
1 0
○
F0.01
Digital frequency
control
DIGITAL FREQ
CTR
Unit’s place of LED:
0:Frequency value can be saved at power off
1:Frequency value can not be saved at power off
Ten’s place of LED:
0:Stopping frequency holding
1:Stopping frequency recovery F0.02
Note :Only for F0.00=0,1,2
1 00
○
F0.02
Set operating
frequency in digital
mode
RUN FREQ SET
F0.13~F0.12
(Only for F0.00=0. 1. 2)
0.01Hz 50.00Hz
○
F0.03
Methods of inputting
operating commands
RUN
COMMAND
SELE
0:Input via panel:(LED turns on);
1:Input via terminal:(LED off);
2:Inpuy via serial port:(LED flashes)
1 0
○
F0.04 Running direction setup
RUN
DIRECTION
0:Run forward 1:Run reverse 1 0
○
F0.05
Maximum output
frequency
MAX OUTPUT
FREQ
Max{50.00,upper limit of frequency F0.12}~650.0Hz 0.01Hz 50.00Hz
×
F0.06
Basic operation
frequency
BASE RUN
FREQ
1.00~650.0Hz 0.01Hz 50.00Hz
×
F0.07 Max output voltage
MAX OUTPUT
VOLT
1~480V 1V
Drive’s rated
value
×
F0.08 Type selection MODEL SELE
0:Type G(suitable for load with constant torque)
1:Type P(suitable for load of pumps and fans)
Note:Valid for the drive of 45kW or below or the type
G/P integrated drive
1 0
×
F0.09 Torque boost
TORQ
BOOST
0.0:(auto)
0.1%~30.0%
0.1% 0.0%
○
F0.10 Acc time 1 ACC TIME1
0.1~3600
Note:
Default unit is second; Unit of Acc/Dec time is defined
by F9.09
0.1
5.5kW~ 22kWG:
6.0s
30kW~ 280kWP:
20.0s
○
F0.11 Dec time 1 DEC TIME1
F0.12 Upper limit of frequency
UPPER FREQ
LIMIT
Lower limit of frequency F0.13~Maximum frequency
F0.05
0.01Hz 50.00Hz
○
F0.13 Lower limit of frequency
LOWER FREQ
LIMIT
0.00~upper limit of frequency F0.12 0.01Hz 0.00Hz
○
F0.14 V/F curve setting
V/F CURVE
MODE
0: User-defined V/F curve(decided by F0.15~F0.20)
1: Torque-stepdown characteristic curve 1 (2.0 order)
2: Torque-stepdown characteristic curve 2 (1.7 order)
3: Torque-stepdown characteristic curve 3 (1.2 order)
1 0
×
F0.15 V/F frequency value F3 V/F FREQ3 F0.17~F0.06 0.01Hz 0.00Hz
×
F0.16 V/F voltage value V3 V/F VOLT3 F0.18~100.0% 0.1% 0.0%
×
F0.17 V/F frequency value F2 V/F FREQ2 F0.19~F0.15 0.01Hz 0.00Hz
×
F0.18 V/F voltage value V2 V/F VOLT2 F0.20~F0.16 0.1% 0.0%
×
F0.19 V/F frequency value F1 V/F FREQ1 0.00~F0.17 0.01Hz 0.00Hz
×
F0.20 V/F voltage value V1 V/F VOLT1 0~F0.18 0.1% 0.0%
×
