Parameter Name Setting range Min. unit Default Mod.
F1.10
Switching point of OD complet maintaining
torque
0.0% ~ 100.0% (motor rated torque) 0.1% 50.0%
○
F1.11 OD complet maintaining torque 0.0% ~ 100.0% (motor rated torque) 0.1% 50.0%
○
F1.12
OD operation curve selection in distance
control
0: selecting manually preset curve
1: selecting optimum curve by auto-learning
1 0 ×
F1.13 OD optimum curve correction factor 3.0% ~ 15.0% (door width) 0.1% 10.0%
○
F1.14 ~ F1.15 Reserved
5.3 CD Operation Parameters F2
Parameter Name Setting range Min. unit Default Mod.
F2.00 CD start creep time for speed control 10 ~ 9999ms 1ms 500ms
○
F2.01 CD start creep distance 0 ~ 30.0% (door width) 0.1% 15.0%
○
F2.02 CD start creep speed 1.00 ~ 25.00Hz 0.01Hz 6.00Hz
○
F2.03 CD Acc time 0.1 ~ 3600s 0.1s 2s
○
F2.04 CD reference frequency 0.00 ~ F0.04 max frequency 0.01Hz 15.00Hz
○
F2.05 Rush hour operation CD speed 0.00 ~ F0.04 max frequency 0.01Hz 20.00Hz
○
F2.06 CD speed decrease point in distance control 60% ~ 95% (door width) 0.1% 70.0%
○
F2.07 CD Dec time 0.1 ~ 3600s 0.1s 2s
○
F2.08 CD ending creep speed 0 ~ 15.00Hz 0.01Hz 2.00Hz
○
F2.09 CD position limit in distance control 1 ~ 9999 (pulse number) 1 600
○
F2.10
Swithcing point of CD complete maintainging
torque
0.0% ~ 100.0% (motor rated torque) 0.1% 50.0%
○
F2.11 CD complete maintainging torque 0.0% ~ 100.0% (motor rated torque) 0.1% 50.0%
○
F2.12 CD speed for EFS 5.00 ~ 25.00Hz 0.01Hz 10.00Hz
○
F2.13 CD operation curve selection in distance control
0: selecting manually preset curve;
1: selecting optimum curve by auto-learning
1 0 ×
F2.14 CD optimum curve correction factor 3.0% ~ 15.0% (door width) 0.1% 10.0%
○
F2.15 Distance control CD door locking point
000 ~ 9999
1 800
○
F2.16 CD speed after door locking point
0.00 ~ 20.00Hz 0.01Hz 5.00Hz
○
5.4 Enhanced Function Parameters F3
Parameter Name Setting range Min. unit Default Mod.
F3.00 INI operation speed 0.00 ~ 20.00Hz 0.01Hz 5.00Hz
○
F3.01
OD time limit 0 ~ 3600s 1s 300s
○
F3.02
CD time limit 0 ~ 3600s 1s 300s
○
F3.03
Slow speed operation time limit 0 ~ 3600s 1s 400s
○
F3.04
Delay time for external OD command 0 ~ 9999S 1s 0s
○
F3.05
Delay time for external CD command 0 ~ 9999S 1s 0s
○
F3.06
Position of safety edge lift signal output 0% ~ 40.0% (door width) 0.1% 10.0% ×
F3.07
Function selection of OD upon CD obstruction 0: stop; 1: open the elevator door 1 1 ×
F3.08
CD obstruction sensitivity 0 ~ 150.0% (motor rated torque) 0.1% 100.0%
○
F3.09
Dec time upon CD obstruction 10 ~ 2500ms 1ms 300ms
○
F3.10
OD obstruction sensitivity 0 ~ 150.0% (motor rated torque) 0.1% 0%
○
F3.11
Maintaining time for complete OD in demo mode 1 ~ 3600s 1s 2s
○
F3.12
Maintaining time for complete CD in demo mode 1 ~ 3600s 1s 2s
○
F3.13
Preset CD/OD times in demo mode 0 ~ 9999 1 0
○
F3.14
CD/OD times record in demo mode 0 ~ 9999 1 0
○
F3.15
Auto reset times upon fault 0 ~ 100 1 0 ×
F3.16
Torque enhance coefficient 100% ~ 350% 1% 115% ×
